Autel MaxiCom Ultra Lite

Operating System

Android 7.0

Processor

Samsung Exynos8895V octa-core Processor (2.3GHz Quad-core Mongoose + 1.7GHz Quad-core A53)

Memory

4GB RAM & 256GB On-board Memory

Display

12.7 inch TFT-LCD with 2732 x 2048 resolution & capacitive touch screen

Connectivity

WiFix2 (802.11 a/b/g/n/ac 2x2 MIMO)

BT v.2.1 + EDR

GPS

USB 2.0 (Two USB HOST Type A, one USB mini device)

HDMI 2.0

SD Card (Support up to 256GB)

Camera

Rear: 16 Megapixel, Autofocus with Flashlight

Front: 5 Megapixel

Sensors

Gravity Accelerometer, Ambient Light Sensor (ALS)

Audio Input/Output

Microphone

Dual Speakers

3-Band 3.5 mm stereo/standard headset jack

Power and Battery

18000mAh 3.8V lithium-polymer battery

Charging via 12V AC/Dcpower supply with the temperature between 0°C and 45°C

Input Voltage

12V/3A Adapter

Operating Temp.

0 to 50°C (32 to 122°F)

Storage Temperature

-20 to 60°C (-4 to 140°F)

Dimensions (WxHxD)

366.5 mm (14.43") x 280.9 mm (11.06") x 34 mm (1.34")

Weight

2.18kg (4.81 lb.)

Protocols

CANFD, DoIP, PLC J2497, ISO-15765, SAE-J1939, ISO-14229 UDS, SAE-J2411 Single Wire Can (GMLAN), ISO-11898-2, ISO-11898-3,
SAE-J2819 (TP20), TP16, ISO-9141, ISO-14230, SAE-J2610 (Chrysler SCI), UART Echo Byte, SAE-J2809 (Honda Diag-H), SAE-J2740 (GM
ALDL), SAE-J1567 (CCD BUS), Ford UBP, Nissan DDL UART with Clock, BMW DS2, BMW DS1, SAE J2819 (VAG KW81), KW82, SAE J1708,
SAE-J1850 PWM (Ford SCP), SAE-J1850 VPW (GM Class2)
